Below are complete technical parameters of our mainstream horizontal straw baler series:
表格
Model | Main Motor Power | Feeding Bin Size | Finished Bale Size | Overall Machine Dimension | Net Weight |
SX100 | 18.5kW | 1100700400mm | Custom 200–400mm width | 280018002500mm | 2.8t |
SX120 | 22kW | 1200750450mm | Custom 250–450mm width | 300019002600mm | 3.3t |
SX160 | 30kW | 1500900500mm | Custom 300–500mm width | 360023002800mm | 4.2t |
SX200 | 37kW | 18001000550mm | Custom 350–600mm width | 400026003000mm | 5.5t |
Why These Specifications Matter
Stable high hydraulic compression force delivers high-density bales, avoiding loose bales during long-distance sea transportation to South America, Central Asia and Southeast Asia.
Standard production cycle 90–120 seconds per bale, supporting all-day non-stop mass production without workflow bottlenecks.
Independent PLC control system supports one-click automatic circulation, real-time fault alarm and simple parameter adjustment, lowering operator training difficulty.
Extra-large horizontal feeding inlet supports direct feeding by forklifts and conveyor belts, improving feeding efficiency greatly.
Who Benefits from This Horizontal Hydraulic Straw Baler?
Straw Recycling Stations & Biomass Power Plants
Recycling enterprises processing tons of crop residues every day rely on this baler to compress straw into neat bales for biomass fuel delivery. Greatly cut logistics and warehousing costs for bulk biomass raw materials.
Animal Feed Mills & Forage Processing Factories
Feed manufacturers need stable continuous production of compressed forage blocks. The automatic hydraulic baler matches feed assembly lines perfectly, producing uniform feed bales for livestock breeding raw material supply.
Large Farms & Agricultural Cooperatives
Farmers and planting bases face big troubles of leftover straw stacking and burning bans. This baler turns waste straw into salable biofuel or livestock bedding materials, realizing harmless treatment and resource reutilization of agricultural waste.
Wood Processing & Furniture Factories
Wood workshops generate large volumes of wood shavings, sawdust and wood chips. The baler compresses wood scraps to save factory floor space and sell wood waste for biomass fuel.
Waste Agricultural Product Recycling Companies
Recycling merchants collecting mixed crop residues, waste hay and crop husks can use one machine to process all light biomass materials, reducing investment on multiple specialized machines.
Key Features and Customer Benefits
Heavy-Duty Integrated High-Pressure Hydraulic System: Low Failure Rate & Long Service Life
Our straw baler adopts top-grade international hydraulic pumps, valves and thickened high-pressure oil seals, effectively preventing oil leakage during long-hour continuous operation. Reinforced thick steel hydraulic cylinders provide stable extrusion pressure without pressure drop.
Customer Benefit: Less frequent maintenance, fewer production halts, suitable for two-shift daily operation and high-temperature tropical regions. Optional condenser cooling pipe upgrade stabilizes hydraulic oil temperature for 24-hour non-stop running.
Horizontal Large Feeding Structure: Labor-Saving & Wide Compatibility
Different from narrow vertical balers with limited feeding capacity, this horizontal design reserves a wide feeding opening. It can be matched with automatic conveyor belts for unmanned feeding, or manual forklift direct feeding without pre-crushing most straw materials. Automatic bale push-out avoids manual bale removal.
Customer Benefit: Save labor cost, simplify factory layout, meet strict occupational safety standards and reduce workplace injury risks.
Intelligent PLC Automatic Control Panel: Easy Operation for New Workers
Full automatic circulation program: feeding → compressing → holding pressure → ejecting bale with one button. Touch screen panel displays running status, error codes and production count in real time. Operators can adjust bale weight and compression pressure directly on the screen.
Customer Benefit: Short training cycle for new staff, stable output, reduce human error caused by manual operation.
Global Multi-Voltage Customization Design
Standard industrial voltage 380V/50Hz for China domestic market. We support customized 220V, 415V, 440V, 60Hz motors to match Argentina, South America, Southeast Asia, Africa and Central Asia local power standards.
Customer Benefit: No extra transformer cost after overseas delivery, direct machine installation and commissioning on-site.
Fully Customizable Bale Size & Weight
Mold internal structure can be modified to produce bales of different width, thickness and single weight according to clients’ container loading requirements or downstream buyer standards. No need to purchase extra machines for different packaging demands.
Customer Benefit: Flexible to adapt to changing market sales requirements and diverse customer order standards.
Wide Raw Material Adaptability
One machine supports all light loose agro & forest materials:
Agriculture: Wheat straw, rice straw, hay, corn husk, rice husk, pasture forage
Forestry: Wood shavings, sawdust, wood chips, crushed branch scraps
Recycling waste: Waste forage, discarded crop stalks, agricultural residual waste
Customer Benefit: Single equipment covers multiple business lines, lower overall equipment investment.
Main Product Range
Horizontal Hydraulic Straw Baler
Vertical Waste Paper & Plastic Baler
Metal Scrap Briquetting Machine
Hydraulic Alligator Metal Shear
Wood Straw Shredder Machine
Gantry Guillotine Metal Shear
Quality Assurance and Certifications
International Standard Compliance
Every straw baler passes strict quality inspection following ISO 9001:2015 quality management system. Machines are CE certified to meet EU safety standards, supporting smooth export customs clearance for global markets including Argentina, Tajikistan, Southeast Asia and Africa.
Premium Raw Material & Core Components
Whole machine frame uses thickened Q235 steel plate with reinforced welding at stress points to avoid deformation under long-term high pressure.
Hydraulic core parts adopt well-known brand hydraulic pumps and valves for stable pressure output and wear resistance.
Electrical control components reach IP54 dustproof and waterproof grade, adapting to dusty farm and recycling workshop environments.
Strict Factory Testing Before Shipment
Each finished baler undergoes 48-hour continuous full-load running test to simulate real production working conditions. Hydraulic pressure stability, automatic cycle program and electrical safety are fully checked. Complete test reports, operation manuals and spare parts lists are delivered together with every machine.
Packing and Delivery Process
Machine main body wrapped with waterproof plastic film, fixed on solid wooden skids; electrical cabinet and hydraulic station packed in fumigation-free wooden cases to avoid collision damage during sea transportation.
We support FOB Qingdao, FOB Tianjin, CIF Buenos Aires and other trade terms, professional container loading scheme to maximize container utilization and reduce sea freight cost. Complete export customs documents including commercial invoice, packing list, CE certificate, factory inspection report can be provided.
How to Calculate ROI of Purchasing This Straw Baler
Transportation Cost Reduction Example
If your factory ships 30 tons loose straw monthly with freight cost $180 per ton, compressing straw to 25% of original volume cuts shipping weight drastically. Monthly freight savings can reach thousands of US dollars, bringing obvious cost reduction within 3–6 months.
Compact uniform bales are favored by biomass power plants and feed factories, who offer 10%–20% higher purchase price compared with scattered straw. The extra sales profit quickly offsets machine investment.
Labor Cost Savings
Automatic feeding and baling system reduces 2–3 full-time workers for medium-scale recycling stations, cutting long-term labor expenditure year by year.
Long Service Life & Low Operating Cost
With regular maintenance, this hydraulic straw baler can run stably for 10–15 years. After deducting electricity, maintenance and labor savings, most customers recover full investment within 12–20 months.
Why Choose Our Straw Baler Factory (Dezhou Shengxin Machinery)
Professional Manufacturing Strength
We are an integrated R&D, production, sales and after-sales factory covering 50,000 square meters production workshop, equipped with CNC cutting machines, automatic welding equipment and dedicated hydraulic test benches. Our engineering team owns multiple hydraulic compression technology patents for biomass balers.
Direct Factory Competitive Price
No intermediate dealers mark-up, all balers are sold at factory direct price. Volume order discounts are available for recycling chain companies, machinery distributors and large agricultural groups.
Rich Global Export Experience
Our straw balers have been exported to more than 60 countries including Argentina, Brazil, Peru, Tajikistan, Kazakhstan, Malaysia, Nigeria and other regions. We are familiar with international logistics, customs document preparation and regional voltage customization requirements.
One-Stop OEM & ODM Custom Service
We support customized machine size, bale mold, motor voltage, brand logo printing, and matching conveyor feeding system. Our technical team can design exclusive baling solutions according to customers’ material type, daily output and factory space conditions.
Frequently Asked Questions
What is the HS code for straw baler export customs declaration?
General HS code 843340, different countries may have slight classification differences. Our export team will provide accurate customs declaration documents to guarantee smooth clearance.
Can this baler process straw and wood chips mixed materials?
Yes, the horizontal large feeding bin and high-pressure hydraulic system can compress mixed light agro & forest materials without blockage.
Can you customize the machine voltage for Argentina market?
Absolutely. We can configure 440V/60Hz three-phase motors according to South America local power supply without extra transformers.
Is there optional upgrade for continuous high-temperature work?
Yes, we provide condenser water cooling pipe upgrade kit, which stabilizes hydraulic oil temperature and supports 24-hour non-stop heavy-duty production in hot areas like Argentina.
What after-sales support can we get after ordering?
We provide 12-month full machine warranty, lifetime remote technical guidance, global spare parts supply and operation training videos. Overseas on-site installation guidance can be arranged upon request.
Can you send machine running videos for reference?
Sure, we can provide real workshop production videos, finished bale effect videos and factory workshop virtual tour for your evaluation before order confirmation.
Request a Free Quotation & Technical Consultation
Start optimizing your agricultural waste recycling business with our reliable horizontal straw baler. Whether you compare baler models, calculate production output or need factory direct price, our professional sales team is ready to offer full support:
Custom quotation matched with your daily processing capacity
Complete technical specification sheets and equipment operation videos
Real customer cooperation case references from your industry
Online virtual factory inspection or offline factory visiting arrangement
Invest in high efficiency, low operation cost and long service life. Choose Shengxin Machinery horizontal straw baler to maximize your agricultural recycling profits.
Website: https://www.sxbaler.com
Mobile / WhatsApp: +86 18865809958
Email: emma@sxbaler.com
Factory Address: Dezhou City, Shandong Province, China
After-Sales Service System
Standard Warranty Policy
12-month full machine warranty or 2000 working hours (whichever comes first), covering all mechanical frames, hydraulic cylinders, motors and electrical control components. Consumable spare parts such as oil seals, filter elements are excluded from free warranty. Extended 3-year warranty service is optional.
Global Technical Support
24/7 online video & telephone technical support to solve operation faults quickly; core spare parts are stocked in our warehouse and can be delivered within 48 hours to reduce production downtime.
Training Service
Remote one-on-one operation & maintenance training via video call; on-site operator training and machine commissioning service available for overseas clients.
Installation & Commissioning Guidance
Detailed installation drawings and operation manuals attached to each machine. Our engineers provide step-by-step remote guidance for hydraulic pipeline connection, electrical wiring and pressure parameter adjustment.
Lifetime Technical Support
We provide permanent machinery technical consultation, equipment transformation suggestion and new industry solution updates for all our customers, no extra charge after warranty expiration.
OEM & ODM Customization Service
Our factory accepts full customization for global distributors and large recycling enterprises:
Custom machine appearance size, feeding bin and bale mold dimensions
Custom motor voltage, frequency and power matching local national standards
Print customer brand logo on machine body, control cabinet and outer package
Design matched automatic conveyor feeding system, condenser cooling system as upgrade options
Provide private packaging and independent export documents for distributors’ resale business
