9YFQ-1.0 Round Bale Pickup Baler

The 9YFQ-1.0 round bale pickup baler is a high-efficiency trailed forage baling equipment specially developed for medium and large livestock breeding farms and straw recycling stations. Connected to tractors via traction structure, it realizes automatic pickup, conveying, roller compression and net binding in one continuous workflow. Fitted with 2300mm large-width cutter-tooth pickup reel and spiral feeding mechanism, the machine delivers smooth material intake without blockage. 18 precision cast compression rollers create compact 1050mm round bales that can preserve silage fresh for 1–2 years without mildew. Qualified for national agricultural subsidies and EU CE compliance, this baler can be freely customized in appearance and configuration, with a 12-month full machine warranty and full spare parts supply service for overseas buyers.

Quantity:
Availability:





Inquire Add to Basket

Model:
9YFQ-1.0
Brand:
Sxbaler
Code:
SX-RB-9YFQ10

Product Overview

9YFQ-1.0 round bale pickup baler is a tractor-trailed integrated baling machine independently developed by our factory for straw silage recycling. It integrates pickup, feeding, compression and net binding functions, eliminating repeated manual material handling and drastically cutting labor costs. The whole machine adopts thickened steel plate frame and heavy-duty bearing components, adapting to harsh field working environments such as uneven ground and wet straw. It has passed national agricultural machinery appraisal with certificate No.T202100370549, eligible for national agricultural purchase subsidies, and obtained complete EU CE technical documents to meet import standards of European, Southeast Asian, Middle Eastern and African markets.

4. Wide Application Scenarios

Medium and large cattle, sheep and goat breeding farms, large-scale pasture bases, centralized straw recycling stations, agricultural cooperatives and comprehensive biomass feed processing enterprises.

5. Full After-sales Support

12-month full machine warranty starting from delivery date. All vulnerable spare parts such as pickup teeth, compression rollers and hydraulic seals are supplied at factory cost price permanently. Our professional technical team provides free remote video guidance for installation, operation, routine maintenance and fault troubleshooting. We can also design a complete straw recycling production line matched with straw crushers, chain conveyor belts and silage wrapping machines based on customer’s processing capacity requirements.

Complete Technical Parameter Table

Traction Type	Trailed, matched with standard tractor three-point suspension
Pickup Width	2300mm, large coverage for high working efficiency
Pickup Tooth Form	Cutter tooth, anti-winding design for dry and fresh straw
Feeding Mechanism	Spiral continuous feeding structure, stable conveying without clogging
Compression Chamber Structure	Full roller extrusion type
Compression Chamber Inner Width	1250mm
Finished Bale Diameter	1050mm
Quantity of Compression Rollers	18 sets
Compression Roller Diameter	190mm, wear-resistant alloy surface treatment
Binding Mode	Net wrapping (support plastic net or straw rope replacement)
Matched Tractor Power	≥50HP

Core Product Advantages

National official promotion certified model, users can apply for agricultural purchase subsidies locally, effectively lowering procurement costs.
2300mm ultra-wide pickup header covers a large working range, greatly improving daily baling output and suitable for large-area straw harvesting.
Spiral continuous feeding system avoids material blockage even for high-moisture corn straw and soft alfalfa grass.
18 groups of balanced compression rollers provide uniform extrusion force, forming high-density round bales with tight wrapping to isolate air and extend silage storage time.
Simple traction connection design, easy to assemble and disassemble with tractors, flexible to turn and transfer between farm plots.
Complete CE certification, full set of technical files including risk assessment, circuit diagrams and operation manuals provided before shipment for customs clearance.
Flexible OEM customization: body color, brand logo, bale size and auxiliary parts can be adjusted according to client’s production demands.
